One-line problem definition

Key line: When semiconductor microprocessing is blocked, the next option is not only a smaller line width, but also a question of how to fold, place, and verify the circuit within the same process.

AI Times reported on July 7, 2026 that Huawei disclosed production data of the LogicFolding structure to be applied to the next-generation mobile processor Kirin 2026 through ChinaXiv research. The key figure is that the transistor integration was increased by 55% while using the same manufacturing process as the existing Kirin 9030 Pro, and power consumption was reduced by 41% based on the same performance under 25 degrees and 0.9V conditions.

This article is not intended to definitively evaluate Huawei’s product performance. What practitioners need to look at is not the promotional statement, “We will catch up with the 1.4-nano level even without EUV,” but what verification items the same process optimization requires in actual chip introduction decision-making.

Conclusion first

Key line: LogicFolding is not an all-purpose solution that all chip teams can follow right now, but it is a structural optimization strategy worth verifying for organizations with strong process constraints.

There are three recommended targets. First, it is a chip design organization with limited access to the latest EUV process. Second, for product teams like mobile SoCs, power and heat budget are as important as performance. Third, investment and product strategy managers must evaluate performance improvement paths other than “process node upgrade”.

On the other hand, it is clear that there are cases where only observation is necessary. There is no reason to rush for teams that have already secured a stable state-of-the-art process and proven EDA flow, teams that have difficulty handling physical design risks due to a short product release schedule, or organizations that easily misunderstand research paper figures as silicon mass production yield data.

Decomposition of core structure

Key line: The essence of LogicFolding is not “a technology to make chips smaller” but closer to “a design method that refolds the location and connection of the circuit within the same bottom surface.”

From a novice developer's perspective, a semiconductor chip is similar to an apartment complex. Process refinement is a method of building a smaller house on a single piece of land. Logic Folding is a method of maintaining the same land and the same building rules, but changing the building layout and passageways to add more rooms and reduce travel distance.

Structurally, it should be viewed as three layers. First, the logic circuit layer. Blocks such as CPU, GPU, and NPU determine which operations will be performed. Second, the physical placement layer. Determine where the transistors and wiring will be placed on the actual silicon. Third, the power and heat verification layer. Check whether the result of increasing density does not lead to heat generation, voltage drop, or yield problems.

The numbers in the Huawei report should also be read in this connection. The 55% increase in integration does not simply mean “there are more transistors,” but rather claims that physical placement efficiency has improved in the same process. The 41% power reduction is not a “performance increase and electricity consumption reduction,” but a limited comparison that indicates that the power consumption required to achieve the same performance under specific temperature and voltage conditions has decreased.

Explanation of design intent

Key line: The reason for this design is closer to the real issues of supply chain constraints and mobile power budgets than to show off technology.

State-of-the-art chips usually move to finer processes to ensure performance and power efficiency. However, if access to EUV lithography equipment is limited, this path becomes expensive or impossible. Then, the direction of reducing design density, wiring length, and switching loss in the same process becomes relatively important.

LogicFolding also gives up some things. We give up the simplicity of using existing EDA flows and verification practices. As the multi-layer structure becomes deeper, design complexity, heat concentration, debugging difficulty, and mass production yield uncertainty may increase. What we are trying to achieve instead is to secure room for performance and power improvement without changing the process node.

Therefore, this issue becomes thinner if consumed as “China catches up with TSMC without EUV.” A more accurate question is “To what extent can structural optimization replace process refinement in the same process?”

Evidence and comparison

Key line: The criteria for comparison are not top performance, but process accessibility, verification risk, power budget, and mass production feasibility.

Approach	What you get	Losing	Practical verification point
Transfer to cutting-edge EUV process	Proven density/power improvement path	Accessibility to equipment/foundry, cost burden	Process supply and demand, wafer unit price, packaging bottleneck
Logic Folding type same process optimization	Possibility to improve density and power without process changes	Increased difficulty in verifying physical design, heat, and yield	Benchmark range, PVT conditions, mass production yield
Dedicated accelerator or separate ASIC	Maximize the efficiency of specific AI workloads	Reduced versatility, burden on software ecosystem	Real app workload, compiler support, fallback path

According to an AI Times report, Huawei predicted that it could develop to a level equivalent to 1.4 nanometer level integration in 2031. This outlook is meaningful as a roadmap, but when judging practical introduction, it should still be treated as a “hypothesis before mass production verification”.

Looking at ASML's EUV explanation material, EUV is a key equipment axis for implementing finer patterns with shorter wavelengths. LogicFolding is not a technology to eliminate this axis, but an approach to supplement design in conditions where equipment access is limited.

Actual operation flow / step-by-step execution method

Key one line: When an organization reviews this news, it should not be a summary of the article, but a small experiment to check “Does our chip block have the same effect?”

The first step is to fix the baseline. Document the chip, process, voltage, temperature, clock, and performance goals to be compared. Conditions should be locked, for example, “Compare power and area at 25 degrees, 0.9V, same clock, same workload”.

Second, select a representative block. Rather than comparing the entire SoC at once, pick one block that has a clear bottleneck, such as a CPU subblock, NPU MAC array, or logic around the cache.

Verification input example
- baseline: existing physical design results
- candidate: Candidate placement for LogicFolding application
- metric: area, timing slack, total power, leakage, IR drop, thermal hotspot
- condition: 25C / 0.9V / target frequency fixed
- pass line: Power reduction of more than 15% for the same performance, timing violation 0, within the allowable heat concentration range

Third, combine the EDA reports into one sheet. The results of improving only the area are not sufficient. Timing margin, voltage drop, leakage current, wiring congestion, and heat map must be viewed together.

Fourth, establish a verification plan at the small silicon or FPGA level. Numbers like 55% and 41% in the article are just the starting point for the product team. Even if it is only half-reproduced in its own workload, it can be meaningful, and if it is only reproduced in a specific block, the overall SoC strategy must be different.

Mistakes/Pitfalls

Key line: The biggest mistake is reading research numbers like product specifications.

• Trap 1: Interpret “55% increase in integration” as a 55% reduction in total chip area. To prevent this, you must check which block and baseline the number comes from. The recovery method is to divide it into area reports for each block rather than the entire SoC.
• Pitfall 2: Power reduction figures apply to all temperatures and voltages. The 25 degrees and 0.9V conditions are useful, but mobile devices experience high temperatures, low voltages and peak loads. The recovery method is to create a separate test table for each PVT corner.
• Trap 3: Underestimate the verification cost due to being attracted by the phrase EUV replacement. Even if the process is not changed, the design verification cost can increase. To prevent this, EDA licenses, verification staff, and tape-out risk must be included in the cost table.
• Trap 4: Compare directly with competitors' process roadmaps. LogicFolding is design optimization, and TSMC and Samsung's process nodes are manufacturing platforms. To compare, it must be adjusted to the actual power, performance, and area results of the same workload.

Strengths and limitations

Key line: The strength is that process constraints can be partly attributed to design problems, but the limitation is that the cost comes in the form of verification complexity.

The strengths are clear. There is room for performance and power improvement without changing the process node. In products with strong battery, heat, and size constraints, such as mobile SoCs, the user experience improves simply by reducing power while maintaining the same performance.

However, the limitations are also large. Multi-layer and high-density arrangements can concentrate heat in specific areas. In some cases, power can be reduced by shortening the wiring, but if the connection structure becomes complicated, timing verification and yield management can become difficult.

There are situations where other choices are better. If the majority of operations are specific matrix operations, such as server AI inference, designing a dedicated ASIC or accelerator may be more straightforward. If the product release schedule is urgent, it may be safer to maintain the existing verification flow and reduce the power budget through software optimization.

Points to study more deeply

Key line: To understand this topic, you must study process, physical design, and power verification together, not just a single semiconductor article.

First, we need to look at why EUV is important. EUV is an exposure technology for creating finer circuit patterns, and is a different layer of problem from design optimization such as Logic Folding.

Second, you need to learn PPA. PPA is an abbreviation for Performance, Power, and Area and is a semiconductor design standard that looks at performance, power, and area simultaneously. Good chip design does not improve just one of the three.

Third, you need to look at the PVT corner. PVT is Process, Voltage, Temperature. Even for the same chip, the operating margin varies depending on manufacturing deviation, voltage, and temperature. A single condition number in an article must be checked by expanding to multiple corners.

Execution Checklist + Author's Perspective

Key line: My judgment is “Track it with interest, but let’s not change the product strategy based on numbers without mass production verification.”

• Have you checked whether the baseline of the article is the entire existing Kirin 9030 Pro or a specific block?
• Have you confirmed that the 55% integration and 41% power reduction are values ​​obtained under the same conditions?
• Did you request reports of high temperature, low voltage, and peak load conditions in addition to 25 degrees and 0.9V?
• Have you confirmed that the area improvement does not return to timing violations, IR drops, or heat concentration?
• Have you compared which choice among process transfer, design optimization, and dedicated accelerator directly reduces the bottleneck of our product?
• Have you calculated the total cost including mass production yield and packaging cost?
• Have you measured whether power savings translate into user perceived time under real app workloads?

Definition of Done: Area, power, timing, heat, and yield risks must all pass based on at least 3 PVT corners and actual workload in the same process and same performance target to be listed as a candidate for introduction.

I do not see this news as a signal that “Huawei immediately replaced the cutting-edge process.” Instead, it is seen as a sign that the evaluation criteria for semiconductor competition are expanding from a single process node to design density, supply chain constraints, and verification systems. AI service developers also need to be aware of this change. This is because the model cost and limitations of on-device inference are ultimately determined by the chip's power, heat, and supply network.

Reference material

• AI Times, 2026-07-07, Huawei 3D Logic Folding and Kirin 2026 production data report
• AI Times, 2026 related report, background on Huawei’s 1.4nm challenge without EUV
• ASML, EUV lithography technology description
• TSMC, Logic technology official overview
• U.S. Bureau of Industry and Security, advanced computing and semiconductor export controls
